| Place of Origin: | Shanghai, China |
| Brand Name: | Raylaser |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $31,500.00/sets 1-2 sets |
|
Detail Information |
|||
| Application: | LASER CUTTING | Applicable Material: | Metal |
|---|---|---|---|
| Condition: | New | Laser Type: | Fiber Laser |
| Cutting Area: | 1500mm*3000mm | Cutting Speed: | 0~100m/min |
| Graphic Format Supported: | AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP | Cutting Thickness: | 0~30mm |
| CNC Or Not: | Yes | Cooling Mode: | WATER COOLING |
| Control Software: | CYPCUT | Laser Source Brand: | MAX Raycus |
| Laser Head Brand: | Raytools | Servo Motor Brand: | Yaskawa |
| Guiderail Brand: | HIWIN | Control System Brand: | Cypcut |
| Weight (KG): | 4500 KG | Key Selling Points: | High Productivity Low Maintenance |
| Optical Lens Brand: | Wavelength | Warranty: | 3 Years |
| Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Construction Works , Energy & Mining, Other, Advertising Company | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 3 Years |
| Core Components: | Pressure Vessel, Motor, Gear, Gearbox, Engine, PLC | Mode Of Operation: | Continuous Wave |
| Configuration: | Gantry Type | Products Handled: | Sheet Metal |
| Feature: | Programmable Servo Motor | Performance: | Smart Collision Prevention |
| Speed: | Faster | Precision: | Accuracy |
| Maintenance: | Low Cost | Energy: | Save Up To 30% |
| Service: | Value Added TPM OEE | Consumable: | Original Quality But Low Price |
| Healthy: | Protective Notification | Advantage: | Cutting Edge Technology |
| Competitiveness: | Low Cost Per Parts | ||
Specifications | ||||||||
Working Area | 3000mm X 1500mm | 4000mm X 2000mm | 6000mm X 1500mm | 6000mm X 2000mm | ||||
Positioning Accuracy | ≤0.03mm | ≤0.03mm | ≤0.03mm | ≤0.03mm | ||||
Repositioning Accu. | ≤0.02mm | ≤0.02mm | ≤0.02mm | ≤0.02mm | ||||
Max. accumulating Speed | 100m/min | 100m/min | 100m/min | 100m/min | ||||
Laser Power | 1000W / 1500W / 2000W / 3000W / 6000W / 12000W / 15000W / 20000W / 30000W | |||||||
Laser Source | Max / Raycus / IPG / Boci / BWT | |||||||
Max.Acceleration | 1.2G | 1.2G | 1.5G | 1.5G | ||||
Power Supply | AC380V/50Hz 60Hz | AC380V/50Hz 60Hz | AC380V/50Hz 60Hz | AC380V/50Hz 60Hz | ||||
